The P1.86 LED module offers a 172×86 resolution with a high refresh rate of 3840Hz and over 95% brightness/color uniformity. Its front maintenance design, 5000:1 contrast ratio, and wide 140° viewing angles ensure sharp and consistent visuals. Built for durability, it delivers over 100,000 hours of reliable performance.

Categories: , Brand:

Description

Module Parameter
PixelPitch(mm) : 1.86
LED : 1515
Module Resolution(W*H) : 172*86
Module Size(W*H*D,mm): 320*160*15
Density(dot/㎡) : 288,762
Flatness(mm) : ≤1
Maintenance : Front
Material : PlasticBottomShell

Optical Parameter
Single-dotbrightness calibration :Available
Single-dot color calibration : Available
Brightness(cd/㎡) :400-450
ColorTemp(K) :3200-9300Adjustable
Viewing Angle(H/V,°) : 140/140
Emitting point center distance deviation:<3%
Brightness/Coloruniformity : ≥95%
ContrastRatio : 5000:1

Electrical Parameter
MaxPower Consumption(W/㎡) : 372
AvgPower Consumption(W/㎡) : 124
Power Supply : 110-220VAC±15%

Processing Parameter
Driver Mode : ConstantCurrent
Scan Rate : 43
FrameRate(Hz): 60
Refresh Rate(Hz) : 3840
Color Depth(bits) : 12~14

Operating Parameter
Receiving Card : 75
Lifespan(hr) : ≥100000
Operating Temp(℃): -10~40
Storage Temp(℃) : 0~40
Operating Humidity(%RH) : 10%~65%
Storage Humidity(%RH) : 10%~60%

  • Highportability: lightweight and easy to install and disassemble.
  • Highrefresh rate: 3840Hzrefresh enables betterdisplay effect.
  • Higherresolutiondelivers a moredetailed display effect.
  • Magneticdesign allows for front installation and maintenance.
  • Adopts constant current drive LED for even light emitting and lower powerconsumption

.

.
